DFF Analysis
Design for Fabrication (DFF) Analysis pulls fabrication rules into the PCB design domain and presents them in a way that to understood by the PCB designer. DFF Analysis verifies the PCB database to find issues that may cause problems when entering into the fabrication process.
- Net_list Check
- Minimum spacing clearance between Pad to Traces
- Drill to Drill Clearance
- Acute Angles
- Silk Screen Text Overlaping on Mask
- Slivers
- Solder Mask Slivers
- Minimum Annular Ring
- Solder Mask Coverage
- Pth to Copper
- Traces Exposed to the Mask
- Isolated Thermal
- Starved Thermal Vias
- Pth to Copper (Via on Split)
